Load Cell ZEMIC H3 100kg Murah Bergaransi

  • Merk : ZEMIC
  • Minimal Pembelian : 1 Unit
  • Pengiriman : 0 Hari Setelah Pembayaran
  • Lokasi : DKI Jakarta - Jakarta Barat
  • Harga : KONTAK KAMI
  • Dilihat : 14 Kali
  • Pembaruan : 18-12-2025 23:41
Dapatkan Spesifikasi Harga Load Cell ZEMIC H3 100kg Murah Bergaransi Produk Terbaik dari CV. BERKAH TIMBANGAN INDONESIA Jual Timbangan Digital, Jual Load Cell, Jual Indikator Timbangan, Jual Anak Timbangan, Jual Alat Kemetrologian, Jasa Service Timbangan, Jasa Kalibrasi Timbangan & Jasa Tera Timbangan.

Produk Detail

Jual Load Cell ZEMIC H3 100kg dengan harga lebih murah, barang dijamin original, berkualitas bagus dan bergaransi resmi selama 2 tahun.

Produk detail Load Cell ZEMIC H3 100kg :
Merk : ZEMIC
Type : H3
Kapasitas : 100kg
Made in : China

Short description :
- S type load cell
- Nickel plated alloy steel IP67
- Tension and compression applications
- Suitable for hanging, hopper and other weighing devices
- Also available in imperial capacities and dimensions

Specification :
- Accuracy Class : OIML R60 C3 OIML R60 C4 C3
- Output Sensitivity ( = FS ) mV/V : 2.0 ± 0.004
- Maximum Capacity ( Emax ) : 25kg, 50kg, 100kg, 150kg, 200kg, 250kg, 300kg, 500kg, 750kg, 1t, 1,5t, 2t, 2,5t, 3t, 5t, 7,5t, 10t, 15t, 20t, 30t
- Max. Number of Load Cell Intervals nLC : 3000 4000 3000
- Ratio of min. LC Verification Interval Y = Emax / vmin : 10000 20000 10000
- Combined Error %FS : ≤± 0.020 ≤± 0.018 ≤± 0.020
- Creep Error (30 minutes) %FS : ≤± 0.016 ≤± 0.012 ≤± 0.016
- Temperature Effect on Zero (ZTC) %FS/10°C : ≤± 0.015 ≤± 0.010 ≤± 0.015
- Temperature Effect on Sensitivity (STC) %FS/10°C : ≤± 0.011 ≤± 0.009 ≤± 0.011
- Zero Balance %FS : ≤± 1.5
- Safe Overload %FS : 150
- Ultimate Overload %FS : 300
- Excitation, Recommended Voltage V : 5 ~ 12
- Excitation, Maximum Voltage V : 18
- Input Resistance Ω : 350 ± 3.5
- Output Resistance Ω : 351 ± 2.0
- Insulation Resistance (50V) MΩ : ≥5000
- Compensated Temperature °C : -10 ~ + 40
- Operating Temperature °C : -35 ~ + 65
- Storage Temperature °C : -40 ~ + 70
- Element Material : Nickel plated alloy steel
- Ingress Protection (acc. to EN 60529) : IP67
- Recommended Torque on Fixation Bolts : Nm M8:25, M10:50, M12:75, M20:400, M33:1800, M42:3600
- ATEX Classification (optional) : II 1G Ex ia IIC T4 Ga, II 1D Ex ia IIIC T 200 135°C Da, II 3G Ex ic IIC T4 Gc

Features :
- Cable type : Shielded, 4 conductor cable, conductor AWG 22
- Cable diameter : Ø 5.0mm
- Cable length : 3m for 25kg – 1.5t, 6m for 2t – 30t
- Cable jacket : Polyurethane
- Shield not connected to element

Untuk informasi lebih lanjut mengenai produk Load Cell ZEMIC H3 100kg dan harga terbaiknya dari kami segera hubungi kami sekarang :
CV. BERKAH TIMBANGAN INDONESIA
